We are the only aftermarket torque converter manufacturer that has the equipment capable of testing for converter input torque, output torque, and dynamic torque. This data is critical in determining the stall speed, K-factor, and torque ratio of a given converter. This means we are the only manufacturer that can accurately give you this data for their torque converters, not just a guesswork figure based on incomplete data.

Our posted stall speeds are based on stock vehicles with an input torque of 500 lb•ft. Engine and other vehicle modifications will directly affect stall speed, including true, flash, and breakaway stall speed. All stall speeds are tested using our in-house dynamometer at a 0.0 speed ratio. All stall speeds, K-factors, and torque ratios are based on this 0.0 speed ratio.

Stall Speed: True stall speed is tested by putting the vehicle in drive and holding the throttle wide open while simultaneously holding the brake, so the vehicle remains stationary. When this happens, the torque converter will stall the engine at a certain RPM. When stalled, the engine will not be able to increase RPM until the vehicle is allowed to move. At this RPM, a true full stall is achieved. Do not test for true stall, as it can damage transmission shafts and overheat the torque converter. We have specialized equipment we use to perform this test. The stall speed of a converter is always dependent on engine torque.

Speed Ratio: A converter’s speed ratio can be calculated using the given RPM of a converter’s impeller and turbine. Speed ratio can be found using a simple equation. TURBINE RPM ÷ IMPELLER RPM = SPEED RATIO.

If a converter’s impeller is rotating at 2500 RPM, while its turbine is rotating at 1800 RPM, we would know the converter’s current speed ratio was 0.72. When the vehicle gets up to speed and the lock up clutch engages, the engine and impeller RPM will match the RPM of the turbine, resulting in a speed ratio of 1.0.

Torque Ratio: This number represents torque multiplication. For example, if a converter has a torque ratio of 1.8, then for every 100 lbs of input torque, the converter will deliver 180 lbs of output torque. The higher the torque ratio is, the better the vehicle’s towing ability will be. One way to think of it is to think of a vehicle slowly driving over a street curb. The higher the torque ratio is, the easier it will be to jump the curb.

K-Factor: K-factor is a mathematical equation used to calculate torque converter performance. A dynamometer that can read both input torque and output torque is used to determine K-factor. The K-factor can be found using a simple equation. ENGINE RPM ÷ √INPUT TORQUE = K-FACTOR.

This equation can also be used to find the stall speed. If a vehicle has an input torque of 500 lb•ft, its square root of input torque would be 22.36. If multiplied by a K-factor of 100, the vehicle’s stall speed would be 2236 RPM. Using the same torque converter, with a K-factor of 100, but changing the engine to produce 600 lb•ft of torque, the vehicle’s stall speed would be 2449 RPM. The equation would now read as: √600 × 100 = 2449. A general rule of thumb is to remember that the higher the K-factor is, the higher the engine RPM will be.

AXn10: Will stall approximately 600 RPM above stock. The AXn10 is a high-stall torque converter. It's designed strictly for racing and sled pulling applications. The AXn10 is suitable for vehicles with large turbos and for situations where more engine RPM is required to get the turbo spooled. It helps maintain a higher RPM range for applications where turbo lag needs to be minimized.

Use With: Complete racing or sled pulling vehicles with large turbos and injectors.

Torque Ratio: 2.016

K-Factor: 138.9

BXn10: Will stall approximately 400 RPM above stock. The BXn10 combines higher RPM stall characteristics and more efficient coupling. This design enhances turbo spooling capabilities, making it particularly suitable for larger turbos that require higher RPM to reach efficiency. The BXn10 works well for trucks used for racing and spirited driving while maintaining good street manners relative to other higher stall converters.

Use With: Racing and spirited driving vehicles with some street use.

Torque Ratio: 2.017

K-Factor: 130.0

BX: Will stall approximately 50 RPM above stock. The BX transfers power more efficiently with less RPM slippage as well as allowing for better drivability. The BX improves overall driving experience by reducing excessive engine RPM at cruising speeds, making it a solid choice for street-driven performance trucks. The BX works well for trucks occasionally used for racing or spirited driving while maintaining good street manners.

Use With: Street vehicles occasionally used for spirited driving.

Torque Ratio: 2.087

K-Factor: 113.6

R: Will stall approximately 250 RPM below stock. The R supports a wide range of applications. It provides a reliable spool-up, smooth driving experience while delivering extra pep for performance needs. The R is good all-around converter for a mix of work and play, offering a balance of durability and performance. It's suitable for trucks with small to medium turbo upgrades or light modifications.

Use With: Daily driving, and light to moderate performance setups.

Torque Ratio: 1.830

K-Factor: 100.1

DK: Will stall approximately 400 RPM below stock. It offers improved coupling and efficiency, reducing heat and increasing drivetrain reliability. The DK is a strong option for daily drivers and trucks that handle towing or mild street performance, providing excellent reliability and drivability. It allows for smooth engagement without being overly aggressive.

Use With: Daily drivers and trucks that handle towing.

Torque Ratio: 1.739

K-Factor: 91.1
